| WIRELESS INTERFACES |
| WWAN* |
| 5G NR SUB-6 GHZ WITH 4G LTE-ADVANCED PRO AND 3G FALLBACK (TX64-161) |
5G NR Sub-6: n1, n2, n3, n5, n28, n41, n66, n71, n78, n79; 4G LTE-Advanced Pro: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14 - FirstNet®, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71; 3G: B1, B2, B3, B4, B5, B6, B8, B9; Cat 20 |
| LTE-ADVANCED PRO (TX64-141) |
LTE FDD: B1, B3, B7, B8, B12, B13, B14 - FirstNet®, B20, B25, B26, B28, B29; B30, B32, B48, B66, B71; LTE TDD: B38, B39, B40, B41, B42, B43, B46; 3G: B1, B2, B4, B5, B8; Cat 18 |
| 4G LTE-ADVANCED WITH 3G FALLBACK (TX64-121) |
LTE FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B20, B25, B26, B28, B29, B30, B66; LTE TDD: B38, B40, B41; 3G: B1, B2, B4, B5, B8; Cat 11 |
| CONNECTOR |
(2) or (4) x 50 Ω SMA per module (center pin: female) |
| SIM SLOTS |
(2) Mini-SIM (2FF) per module |
| SIM SECURITY |
SIM slot cover plate included |
| WI-FI |
| DUAL MODULES |
Private backhaul: 4 x 4 MU-MIMO 5 GHz 802.11 a/n/ac Wave 2, up to 128 stations per module, 1.733 Gbps (max)
Public Wi-Fi: 2 x 2 MIMO 2.4/5 GHz 802.11 a/b/g/n/ac, up to 128 stations per module, 867 Mbps (max) |
| HOTSPOT |
Captive portal, customizable splash page |
| AUTHENTICATION |
Basic ToS acceptance, Enterprise RADIUS |
| 3RD PARTY SERVICES |
Content filtering, embedded advertising |
| MODES |
Up to 4 access points and 1 client per Wi-Fi module (8+2 total) |
| SECURITY |
WPA/WPA2-personal, WPA/WPA2-enterprise |
| CONNECTORS |
Private backhaul: (4) 50 Ω RP-SMA (center pin: male)
Public Wi-Fi: (2) 50 Ω RP-SMA (center pin: male) |
| BLUETOOTH® |
| MODULE |
BLE 4.2 |
| GPS |
| TECHNOLOGY |
Multi-constellation: concurrent reception of up to 2 GNSS (GPS, Galileo, GLONASS, BeiDou) |
| SENSITIVITY |
-163 dB |
| PROTOCOL |
NMEA 0183 V2.3 sentence output |
| CONNECTOR |
1 x 50 Ω SMA (center pin: female); +3.3 VDC active antenna drive |
| HARDWARE |
| SERIAL |
| PORTS / CONNECTOR |
(1) RS-232; DB-9 male |
| ETHERNET |
| PORTS / CONNECTOR |
(4) RJ-45 |
| STANDARD |
IEEE 802.3; 10/100/1000 Base-T |
| USB |
| PORTS |
3 |
| STANDARD |
USB 3.0, Type A |
| MEMORY |
| RAM |
2 GB |
| FLASH |
8 GB (CFAST card) |
| PHYSICAL |
| DIMENSIONS (L X W X H) |
260 mm x 196 mm x 67 mm (10.2 in x 7.8 in x 2.6 in) |
| WEIGHT |
3.3 kg (7.25 lbs) |
| STATUS LEDS |
Power, WWAN (signal, service) per module, Wi-Fi service (per module), GNSS service, LAN (link, activty) |
| ENCLOSURE |
IP40 aluminum alloy |
| POWER |
| POWER INPUT |
9 - 36 VDC, 60 W minimum power source required |
| POWER CONSUMPTION |
28 W typical (idle); 41 W (peak RF Tx/Rx) |
| ENVIRONMENTAL |
| MOUNTING |
Flexible mounting options |
| OPERATING TEMPERATURE |
-30° C to 70° C (-22° F to 158° F) |
| STORAGE TEMPERATURE |
-40° C to 85° C (-40° F to 185° F) |
| RELATIVE HUMIDITY |
5% to 95% (non-condensing) @ 25° C (77° F) |
| NEMA |
| SPECIFICATION |
Meets or exceeds the NEMA TS2 environmental requirements (-34° C to 74° C temperature range; 18% to 95% humidity over the temperature range; Vibration: 0.5 g @ 5 Hz to 30 Hz; Shock: 10 g) |
| APPROVALS |
| CELLULAR |
PTCRB, AT&T, FirstNet Ready™, T-Mobile, Verizon, PNTM, Verizon Frontline; visit www.digi.com/resources/certifications for latest cellular certifications |
| SAFETY |
UL 60950/EN62368, CSA 22.2 No. 60950 |
| EMISSIONS/IMMUNITY |
CE, FCC Part 15 Class B w/ IC, EN303413+EN301489-1/-19, CISPR 25, Level 3, ISO 11452-2, ISO 11452-4 |
| ENVIRONMENTAL / INDUSTRIAL |
MIL-STD 810G (temperature, humidity, vibration, shock, dust) |
| VEHICLE |
SAE J1113-2 / J1455, ISO 7637-2/3, ISO 10605, ISO 16750-2 load dump |
| WARRANTY |
| PRODUCT WARRANTY |
3-year** |
