Digi IX10 Cellular Router

New

Rugged, reliable, cost-effective connectivity for critical industrial applications



Digi IX10 is a full-featured cellular router built for trouble-free reliability over a long service life. Its flexible power and connectivity options make it a versatile and cost-effective choice for industrial, digital signage, ATMs, lottery terminals, kiosks and other unattended retail applications that need to provide secure transactions.

Digi IX10 features a RJ-45 serial port supporting both RS-232 and RS-485, as well as built-in dual SIMs for redundant connection. It is capable of operating independently on public LTE networks, with features to assist in network control and management, such as VLAN support, load balancing between cellular and Ethernet WANs, dual APNs and configurable APN search. Digi IX10 also offers low-touch and no-touch provisioning.

Gain critical insights into your deployed devices and manage your network with Digi Remote Manager® — the command center for your deployment. Digi Remote Manager (Digi RM) is a cloud-based solution that facilitates easy setup, mass configuration, maintenance and support for hundreds or even thousands of remote Digi devices. Digi RM empowers you to evaluate, update and configure your Digi enterprise products, while providing easy visibility into the health of your network.

In the event of an interruption to your primary network connection, Digi RM also provides secure terminal access for out-of-band management access to edge devices via Digi IX10 via serial port and command-line interface. In addition, Digi IX10 offers the convenience of a global SKU which simplifies inventory control for global distribution and deployment.

Manage Your Network Your Way

Remote device management: network-wide updates, data insights and control. Digi Remote Manager delivers centralized visibility and automates processes at your command, with actionable 24/7 remote monitoring.

Automated Network Monitoring
Automated Network Monitoring

To keep tabs on dozens, hundreds or thousands of active connected devices requires network monitoring software. Human eyes can't keep up. With Digi RM remote monitoring tools, you're in command. As your IoT device management platform, Digi RM watches your network for disruptions and intrusions, and lets you know when you need to take action. Set alerts for important conditions. Get reports on network performance. Check on any device, anywhere, anytime.

Configuration Management
Configuration Management

Digi Remote Manager has what other IoT device management platforms don't: the ability to configure all of your devices at once, make individual configuration changes, and still manage those specialized configurations in groups. Create group and individual configurations. Deploy rapidly and accurately. Let Digi RM monitor device security.

Firmware Updates
Firmware Updates

Today's IoT devices are smarter, more feature rich, and have more tasks to perform at the edge. And they are not static. You may need to update firmware to enhance functionality, download custom scripts, keep your devices in compliance with corporate security policies, or deploy patches for threats to IoT security. Digi Remote Manager puts the network management tools in your hands to deploy firmware updates or send files to your devices in minutes, even if you have a network of many thousands of devices. Manage your dynamic network with a few clicks. Keep your devices secure.

Edge Computing
Detection and Troubleshooting

Digi RM is always on, even during your network manager’s off hours. As your network monitoring solution, Digi RM lets you know when issues arise, sending alerts and delivering reports so your team can rest easy. At any time, they can gain the insights needed on the health of the entire network or individual devices and remotely troubleshoot, test and reboot devices as needed. Put network monitoring tools to work for you, so you can work smarter.

Compare Industrial Routers

Compare Industrial Routers
TrustFence

Digi TrustFence

Digi TrustFence is the security framework for Digi cellular routers. The TrustFence framework requires security to be designed in at the ground floor, resulting in a new security orientation for cellular devices. The built-in security of Digi TrustFence gives you secure connections, authenticated boot, encrypted data storage, secure software updates, and excludes all insecure ingress protocols.

Learn More

Related Resources

Enable Leading Global Edge Cellular IoT Solutions Enable Leading Global Edge Cellular IoT Solutions The new Digi IX20 industrial-grade cellular router is the next-gen successor to the Digi WR21. Digi IX20 delivers better... RECORDED WEBINAR Meet the Digi Accelerated Linux Operating System (DAL OS) Meet the Digi Accelerated Linux Operating System (DAL OS) DAL OS delivers sophisticated device functionality I WANT THAT Robust Solutions for Connected Systems in Buildings Robust Solutions for Connected Systems in Buildings Building managers, as well as OEMs that provide supporting services and technology for building management, are finding that... RECORDED WEBINAR Digi IX10 Datenblatt (Deutsch) Digi IX10 Datenblatt (Deutsch) Robuste, zuverlässige, kostengünstige Konnektivität für kritische industrielle Anwendungen VIEW PDF Meet the Digi IX10 Industrial Router Meet the Digi IX10 Industrial Router The Digi IX10 industrial cellular router is the newest member of the Digi IX product line – designed for a wide range of... WATCH VIDEO Industrial IoT: Connectivity for Rugged Applications Industrial IoT: Connectivity for Rugged Applications Selecting the connectivity solution for an application in a challenging environment requires some thought. In this article we... READ BLOG Wireless Digital Signage Solutions to Engage and Inform Visitors Wireless Digital Signage Solutions to Engage and Inform Visitors Secure, reliable LTE and long-range RF connectivity for flexible, high-impact indoor and outdoor displays I WANT THAT Press Release Digi International Unveils Industrial-Grade Digi IX10 Router Reliable, secure, rugged, and cost-effective Digi IX10 provides rightsized connectivity for industrial infrastructure, critical... READ PRESS RELEASE Digi IX10 Datasheet Digi IX10 Datasheet Rugged, reliable, cost-effective connectivity for critical industrial applications VIEW PDF The Top 5 Considerations for Migrating to 4G, 5G and Beyond The Top 5 Considerations for Migrating to 4G, 5G and Beyond Preparing for 2G and 3G sunsets VIEW PDF Digital Signage & Interactive Kiosks Digital Signage & Interactive Kiosks VIEW PDF

All related resources
Cellular Routers
IX10-00G4 Digi IX10 - LTE Cat 4 Global
  • (1) Ethernet
  • RS-232/485
  • No accessories
IX10-00G4 HOW TO BUY
Contact Us
Accessories
76002104 Power supply with plug tips for US, UK, EU, AU 76002104 HOW TO BUY
Contact Us
76002103 (1) Cellular antenna (order quantity 2) 76002103 HOW TO BUY
Contact Us
76002095 DIN rail clip kit 76002095 HOW TO BUY
Contact Us
76000723 Connect EIA 422/485 Devices to Digi MEI products that have 10 pin RJ45 connectors 76000723 HOW TO BUY
Contact Us
Digi Remote Manager
Digi Remote Manager is the technology platform enabling and automating the deployment, monitoring and management of thousands of devices from a single point of command. Compare Digi’s multiple offerings and varying subscription terms to meet your business needs.   GET STARTED
SPECIFICATIONS Digi IX10
CELLULAR
CERTIFICATIONS Visit https://www.digi.com/resources/certifications for latest certifications
LTE (G4) LTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B38, B39, B40, B41
3G: B1, B2, B4, B5, B6, B8, B19
2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz
CONNECTORS (2) 50 Ω SMA (center pin: female)
SIM SLOTS (2) Mini-SIM (2FF)
SIM SECURITY Behind SIM cover, secured with screw (#1 Phillips)
SOFTWARE AND MANAGEMENT
REMOTE MANAGEMENT Digi Remote Manager®; SNMP v2/v3 (user installed/managed)
LOCAL MANAGEMENT WebUI (HTTP/HTTPS); CLI (Telnet, SSH)
MANAGEMENT / TROUBLESHOOTING TOOLS FTP client, SCP; protocol analyzer with PCAP for Wireshark; event logging with syslog and SMTP client; NTP/SNTP; Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute
MEMORY 256 MB RAM, 256 MB flash
ETHERNET
PORTS (1) RJ-45; 10/100 Mbps (auto-sensing)
SERIAL
PORTS (1) RJ-45 10-pin (10P10C); RS-232/485; software selectable
- RS-232 DTE (RXD, TXD, RTS, CTS, DTR, DCD, DSR, RI)
- RS-485 (TX/RX+; RX/TX-); half-duplex
PHYSICAL
DIMENSIONS (L x W x H) 118 mm x 88 mm x 35 mm (4.65 in x 3.46 in x 1.38 in)
WEIGHT 0.39 kg (0.86 lb)
STATUS LEDs Power, Internet, SIM 1, SIM 2, SIM fail, LTE, signal strength (5)
ENCLOSURE Glass-filled polyphenylene sulphide (PPS) / IP30
POWER REQUIREMENTS
POWER INPUT 9 - 30 VDC, 1.0 A maximum
POWER CONSUMPTION 2.5 W typical (idle); 6 W typical (peak Tx/Rx)
ENVIRONMENTAL
OPERATING TEMPERATURE -40° C to 70° C (-40° F to 158° F); device performance may be impacted above 50° C (122° F)
RELATIVE HUMIDITY 5% to 95% (non-condensing)
APPROVALS
CELLULAR Visit https://www.digi.com/resources/certifications for latest cellular certifications
SAFETY IEC62368-1, CB, EN62311
ENVIRONMENTAL ROHS3
EMISSIONS / IMMUNITY CE; RED; FCC Part 15, Subpart B; ICES-003; AU/NZS CISPR32
WARRANTY
PRODUCT WARRANTY 3-year*
*Standard 3-year warranty upgradeable to 5 years with purchase of a Digi Remote Manager Premier 5-year subscription applicable to the product purchased only at the time of product purchase and with product registration at that time in Digi Remote Manager.

ENTERPRISE SOFTWARE Description
PROTOCOL SUPPORT HTTPS, FTP client, SSL, TLS v1.2, SCP (client and server), SFTP, SMTP client for use by scripts and the command line, SNMP (v2/v3), SSH; remote management via Digi Remote Manager®; protocol analyzer, ability to capture PCAP for use with Wireshark; DynDNS; dynamic DNS client compatible with BIND9/No-IP/DynDNS; captive portal, Intelliflow; Nagios, DNS server, NTP server, multicast, mDNS, IPerf
SECURITY IP filtering, stateful firewall, custom firewall rules (iptables), address and port translation, TLS 1.2 and above, OpenVPN client and server, VPN tunnels; Authentication: RADIUS, TACACS+; certificates; MAC address filtering; VLAN support
VPN IPSec with IKEv1, IKEv2, NAT Traversal; OpenVPN client and server; GRE VPN tunnels; Cryptology: SHA-1/256/384/512, MD5, RSA; Encryption: 3DES and AES up to 256-bit (CBC mode for IPsec); Diffie Hellman: DH groups 1-32 (CURVE448)
ROUTING/FAILOVER IP pass-through; NAT, NAPT with IP port forwarding; GRE; multicast routing; Routing protocols: RIP (v1, v2) OSPF, BGP; IP failover: VRRP; automatic failover, Digi SureLink®
OTHER PROTOCOLS DHCP; dynamic DNS client compatible with No-IP/DynDNS
