Digi EX12 LTE Cellular Extender

New

Avoid network outages with primary or backup LTE connectivity; integrate seamlessly with existing infrastructure


  • Redundant cellular connectivity with dual SIMs and Digi SureLink®
  • Digi TrustFence® for built-in device security and data privacy
  • Optional Remote Mounting Kit with bracket, accessories, passive PoE injector and site survey battery pack to identify the best location for optimum cellular reception
  • Automatic cellular carrier detection and switching with Carrier Smart Select™
  • Digi Remote Manager® software for easy setup, mass configuration and management
Digi EX12 LTE cellular extender is an affordable, scalable failover solution that enables you to retrofit your infrastructure for cellular network access. With a carrier-certified, embedded LTE Cat 4 cellular modem, equipped with dual SIM slots, Digi EX12 provides uninterrupted primary or backup connectivity. It protects against downtime by automatically switching to a secondary cellular carrier should the primary SIM lose Internet access. This compact, high-performance device is also compatible with any dual-WAN networking appliance and helps you achieve reliable connectivity at any location using your existing equipment.

Couple the Digi EX12 with a dedicated wireline ISP connection to maximize uptime and ensure reliable network availability for POS systems, ATMs, mobile kiosks, digital signage and more. Deployments are streamlined with installation accessories including an optional Remote Mounting Kit with a disposable battery pack for site survey, mounting bracket and a passive PoE injector for optimizing placement for the best cellular reception.

Digi EX12 can be securely monitored and managed with Digi Remote Manager®, a cloud-based solution that facilitates setup, mass configuration and support for Digi and third-party devices. Digi Remote Manager lets you evaluate, update and configure your Digi enterprise routers and gateways — and the health of your network — at scale, after deployment.

Compare Enterprise Cellular Routers/Extenders

Compare Enterprise Cellular Routers/Extenders
TrustFence

Digi TrustFence

Digi TrustFence is the security framework for Digi cellular routers. The TrustFence framework requires security to be designed in at the ground floor, resulting in a new security orientation for cellular devices. The built-in security of Digi TrustFence gives you secure connections, authenticated boot, encrypted data storage, secure software updates, and excludes all insecure ingress protocols.

Learn More

Related Resources

Digital Signage: Solving Challenges with Technology Digital Signage: Solving Challenges with Technology Digital signage is a dynamic and growing market, supported by the growth of high-speed networks, improved communications... READ BLOG Press Release Digi International Introduces New Routers and Software to Address Next-Generation IoT Connectivity and 5G Needs of Retail, Digital Signage, Transportation, Smart Cities and Beyond TX products for critical infrastructure and intelligent traffic system applications and EX products for enterprise applications... READ PRESS RELEASE Secure, Reliable Connections: Networking Strategies for Remote Workers Secure, Reliable Connections: Networking Strategies for Remote Workers With many more workers connecting remotely today, it is more important than ever to ensure they are connecting securely... RECORDED WEBINAR Cellular Failover Cellular Failover Cellular failover provides the reliable connectivity enterprises, smart cities and industrial IoT applications require for business continuity - quickly connecting to a backup connection from a... LEARN MORE Persistent Network Connections - Digi SureLink Persistent Network Connections - Digi SureLink Network downtime can be costly. But link integrity monitoring and the Digi SureLink “keep-alive” function keep data connections always up, and always on. LEARN MORE FirstNet — Wireless Communications for Public Safety FirstNet — Wireless Communications for Public Safety FirstNet is a nationwide, interoperable, broadband wireless network that delivers pre-emptive voice, text and data for first responders and critical infrastructure, even in times of large-scale... LEARN MORE Digi EX12 Datasheet Digi EX12 Datasheet Avoid network outages with primary or backup LTE connectivity; integrate seamlessly with existing infrastructure VIEW PDF Digi Network Failover Solutions Digi Network Failover Solutions Decrease risk, increase productivity. The case for cellular failover connectivity. VIEW PDF Device-Security Framework - Digi TrustFence Device-Security Framework - Digi TrustFence Digi TrustFence is a device-security framework that simplifies the process of securing connected devices. I WANT THAT

All related resources
SPECIFICATIONS Digi EX12
CELLULAR CONNECTIVITY
CERTIFICATIONS Visit https://www.digi.com/resources/certifications for latest certifications
EX12 R004-OUS LTE: B2, B4, B5, B12, B13, B14, B66, B71; 3G: B2, B4, B5; Transfer rate (max): 150 Mbps down, 50 Mbps up
CONNECTORS (2) 50 Ω SMA (center pin: female)
SIM SLOTS (2) Mini-SIM (2FF); software selectable and hardware switchable
SOFTWARE AND MANAGEMENT
REMOTE MANAGEMENT Digi Remote Manager; SNMP v3 (user installed/managed), encrypted SMS
LOCAL MANAGEMENT WebUI (HTTP/HTTS); CLI (SSH, serial port)
PROTOCOLS RIP, RIPng, OSPFv2, OSPFv3, BGP, Babel, IS-IS
MANAGEMENT / TROUBLESHOOTING TOOLS FTP client, SCP; protocol analyzer with PCAP for Wireshark; event logging with Syslog and SMTP client; NTP/SNTP
MEMORY 256 MB RAM, 512 MB flash
ETHERNET
PORTS (2) RJ-45; 10/100 Mbps (auto-sensing)
SERIAL
PORTS (1) RS-232 (RJ-45)
PHYSICAL
DIMENSIONS (L x W x H) 127 mm x 127 mm x 25 mm (5.0 in x 5.0 in x 1.0 in)
WEIGHT 0.24 kg (8.25 oz)
STATUS LEDs LAN (link = solid, flashing = act), WAN (link = solid, flashing = act), LTE, 5 signal
ENCLOSURE Plastic
POWER REQUIREMENTS
POWER INPUT 18 VDC 1 A
OTHER Includes PSU, cables, antennas and optional Remote Mounting Kit: temporary battery, passive PoE injector, mounting bracket and accessories (see part number for details); Note: only the Digi-supplied power supply and passive PoE injector are recommended for use with Digi EX12
ENVIRONMENTAL
OPERATING TEMPERATURE 0° C to 40° C (32° F to 104° F)
RELATIVE HUMIDITY 5% to 95% (non-condensing)
APPROVALS
CELLULAR PTCRB; US: AT&T, Verizon; Canada
EMISSIONS / IMMUNITY FCC Part 15, Subpart B, Class A; CE, RCM; CAN ICES-3(B)/NMB-3(B)
WARRANTY
PRODUCT WARRANTY 3-year*
*Standard 3-year warranty upgradeable to 5 years with purchase of a Digi Remote Manager Premier 5-year subscription applicable to the product purchased only at the time of product purchase and with product registration at that time in Digi Remote Manager.
