Digi ConnectCore 8X SBC Pro

Intelligent and connected single board computer based on the NXP i.MX 8X; with scalable dual/quad-core performance for industrial IoT applications


  • Industrial i.MX 8X quad/dual-core SOM and SBC platform family
  • Compact Pico-ITX form factor (100 mm x 72 mm)
  • Power management with both hardware and software support for low-power designs
  • Multi-display and camera capabilities with hardware acceleration
  • Pre-certified dual-band 802.11a/b/g/n/ac 2x2 and Bluetooth® 5 connectivity
  • Seamless cellular modem and Digi XBee® 3 integration
  • Built-in Digi TrustFence® device security
  • Yocto Project® Linux® and Android™ support
How to Buy
Digi ConnectCore® 8X SBC Pro delivers a powerful, secure and cost effective off-the-shelf single board computer with complete support for Linux® and Android™. It includes Digi TrustFence® security framework with out-of-box features such as secure boot, encrypted filesystems, protected ports, and more.

Digi ConnectCore 8X SBC Pro offers significantly reduced time-to-market by virtually eliminating the traditional risk, effort, and complexity of custom board designs without sacrificing flexibility or capabilities.

The compact form factor integrates an on-board dual-band antenna option, USB connectivity, Digi XBee® RF connector and cellular connectivity options, multi-display/camera and audio support, external storage and expansion connectors. Digi ConnectCore 8X SBC Pro is highly flexible and can be used in a wide-range of industrial applications, even those with harsh environments.

TrustFenceYocto ProjectBluetoothWi-Fi AllianceNXP Gold PartnerPowered by AWSAndroid

Related Resources

Machine Learning Demo with Digi ConnectCore and ByteSnap SnapUI Machine Learning Demo with Digi ConnectCore and ByteSnap SnapUI Digi International and ByteSnap Design collaborated to develop an interesting and entertaining demo featuring a pirate game... WATCH VIDEO Embedded Computing: Designing for Ease of Manufacturing and Low Cost-of-Ownership Embedded Computing: Designing for Ease of Manufacturing and Low Cost-of-Ownership The embedded system-on-module (SOM) market has grown, offering diverse options for applications ranging from retail displays to... READ BLOG Digi Edge Compute with AWS Greengrass Digi Edge Compute with AWS Greengrass Based on the NXP i.MX line of application processors, Digi ConnectCore embedded SOMs and SBCs deliver the compute power... READ BLOG Press Release Digi International Announces Full Availability of Digi ConnectCore® 8X Development Kits Purpose-built for demanding IoT environments, Digi ConnectCore 8X provides a complete and secure system platform to build... READ PRESS RELEASE Digi ConnectCore 8X SBC Pro Datasheet Digi ConnectCore 8X SBC Pro Datasheet Intelligent and connected single board computer based on the NXP i.MX 8X; with scalable dual/quad-core performance for industrial IoT applications VIEW PDF Digi ConnectCore 8X Datasheet Digi ConnectCore 8X Datasheet Intelligent and connected embedded system-on-module based on the NXP i.MX 8X with scalable dual/quad-core performance for industrial IoT applications VIEW PDF Digi ConnectCore 8X SBC Pro Development Kit Datasheet Digi ConnectCore 8X SBC Pro Development Kit Datasheet Design and build your connected products on an industrial and productization-ready single board computer platform VIEW PDF Yocto Project: The Right Choice for Embedded Systems Design Yocto Project: The Right Choice for Embedded Systems Design VIEW PDF Build vs Buy: Navigating the Choice Build vs Buy: Navigating the Choice In this white paper, we help you to evaluate the best way to optimize your IP and make the right build-vs.-buy decision to meet your goals. VIEW PDF

All related resources

Related Products

SPECIFICATIONS Digi ConnectCore® 8X SBC Pro
APPLICATION PROCESSOR NXP i.MX8QuadXPlus
  • 4x Cortex-A35 cores @ 1.2 GHz
  • 1x Cortex-M4F @ 266 MHz core for real-time processing
  • 1x Tensilica® Hi-Fi 4 DSP
MEMORY Up to 16 GB eMMC, up to 2 GB LPDDR4 (32-bit)
GRAPHICS Multi-stream-capable HD video engine with H.265 (4Kp30), H.264 (1080p60), VP6/VP8 (1080p60), MPEG-2 (1080p60), MPEG4 (1080p),
RealVideo (1080p) decode and H.264 (1080p30) encode; 3D video playback in HD in high-performance families; superior 3D graphics performance with up to 4 shaders
DISPLAYS 2x LVDS/MIPI with backlight control and I2C touch interface
CAMERA 1x 8-bit Parallel Camera Interface, 1x MIPI Camera 2x lanes
AUDIO 2x Line-In, 1 x Line-Out, 1x Mic-In, 1x Headset on 3.5mm audio jack
UART/CONSOLE 4-pin header (console), 2x UARTs on expansion connector
SECURITY Digi TrustFence®, TRNG, TrustZone, Ciphers, Security Control, Secure RTC, Secure JTAG, eFuses (OTP)
ETHERNET 2x Gigabit Ethernet 10/100/1000M with AVB on RJ-45, with 2 LEDs for link/speed/activity
WI-FI 2 x 2 MIMO 802.11a/b/g/n/ac: 2.412 - 2.484 GHz, 4.900 - 5.850 GHz
Security: WEP, WPA-PSK/WPA2-Personal, WPA/WPA2 Enterprise, 802.11i, Soft Access Point Mode (up to 10 clients)
BLUETOOTH Bluetooth® 5
ANTENNA CONNECTORS 2 x U.FL on module
DIGI XBEE RF Standard Digi XBee® socket
USB 2x USB 2.0 Host, 1x USB 3.0 on Type-C connector
PCI EXPRESS MINI CARD* Full-size card support, with on-board Micro SIM slot support – dedicated 3A power supply
OTHER CONNECTIVITY 2x CAN, 1x SPI, 1x I2C, 1x expansion connector
EXTERNAL STORAGE MicroSD
BOOT CONFIGURATION On module eMMC, on SBC microSD, serial downloader and boot from fuses
DEBUG 1x JTAG for i.MX 8X (Tag-Connect), 1x SWD for MCA (Tag-Connect and header)
BUTTONS 1x power button (power on, power off, sleep, wake-up), 1x reset button
LEDS 2x user LEDs (1x yellow, 1x green), 1x power LED (3.3 V)
POWER INPUTS 5 V @ 3.2 A (typical, depending on use-case), 1x coin cell 2-pin header
POWER SUPPLY CONNECTOR Main power supply via 2mm locking barrel connector, or dedicated power connector (2-pin header)
POWER OUTPUTS 3.3 V Out (2-pin header), 5 V Out (2-pin header)
OPERATING TEMPERATURE -40° C to 85° C (-40° F to 185° F)
STORAGE TEMPERATURE -50° C to 125° C (-58° F to 257° F)
RELATIVE HUMIDITY Relative humidity 5% to 90% (non-condensing)
RADIO APPROVALS (PENDING) US, Canada, EU, Japan, Australia/New Zealand
EMISSIONS/ IMMUNITY/ SAFETY (PENDING) FCC Part 15 Class B, EN 55024, EN 55032 Class B, ICES-003 Class B, VCCI Class II,
FCC Part 15 Subpart C Section 15.247 and 15.407, IC (Industry Canada), EN 300 328, EN 301 893, EN 300 440, EN 301 489-1/-17, EN 55024, EN 301 489-3
DESIGN VERIFICATION (PENDING) Temperature: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78;
Vibration/Shock: IEC 60068-2-6, IEC 60068-2-64, IEC 60068-2-27, HALT
MECHANICAL DIMENSIONS 100 mm x 72 mm (3.9 in x 2.8 in)
*PCIe is only supported on wired variants
